Everything within reach of the screen
The 4.3" colour touchscreen makes every charge simpler and more intuitive. It shows the session status, energy delivered, power and operator messages directly, and the language can be chosen right from the screen.
Always connected, even remotely
WiFi, Ethernet and 4G connectivity through a USB modem let you monitor and manage Dazebox Pro remotely too. With the Daze app and Portal you always have access to information and to charging management.
Need advice?
touch display
display
LED
chargers
chargers
chargers
Technical specifications
Product codes:
DT05IT32M5C, DT05IT32M7C, DT05IT32T5C, DT05IT32T7C, DS05IT32MC, DS05IT32TC, DS05IT32MM, DS05IT32TM, DK05IT32M7CP, DK05IT32T7CP, DK05IT32M7MP, DK05IT32T7MP, DK05IT32MCP5S, DK05IT32TCP5S, DK05IT32MMP5S, DK05IT32TMP5S, DS05IT32MCP, DS05IT32TCP, DS05IT32MMP, DS05IT32TMP
General specifications
• Dimensions: 200 x 356 x 110 mm (Pro T) · 250 x 387 x 132 mm (Pro S) · 250 x 387 x 152 mm (Pro TK/SK)
• Installation: wall-mounted or on SD01 / SD11 / SD03 stand
• Operating temperature: from -30° C to +55° C
• Charging mode: mode 3
• IP rating: IP56
• IK rating: IK10
• Display: 4.3” colour touch LCD (800 x 480 px)
• Stand-by consumption: < 3 W
Electric
• Phase: available in single-phase and three-phase versions
• Rated current: adjustable via dip switch from 6.5 A to 32 A
• Maximum power: from 1.5 to 7.4 kW (single-phase) · from 4.5 to 22.2 kW (three-phase)
• Connector cable length: 5 or 7 m (Pro T) · 7 m or coiled up to 5 m (Pro TK)
• Voltage: 230 V ±10% (single-phase) · 400 V ±10% (three-phase)
• Connection: integrated Type 2 cable (Pro T/TK) · Type 2 socket (Pro S/SK)
• Integrated protections: residual current circuit breaker on TK and SK models (Type A, 30 mA)
Functionality
• Connectivity: bluetooth and wifi
• Ethernet: 2 Ethernet ports (daisy chain)
• 4G USB modem: compatible
• Load Balancing: up to 50 charging points (1 master + 49 chargers)
• Charge scheduling: yes
• Self-consumption mode: yes
• Certified MID meter: optional (S, TK, SK models)
• RFID reader: yes, with card identification
• Internal ventilation system: integrated
• OCPP 1.6 Json interoperability: yes
• ISO 15118-20 V2G ready: yes
